|Place of Origin:||China|
|Delivery Time:||3 days|
|Payment Terms:||Paypal & T/T|
RJSQ-001 0-5V Electronic Foot Pedals Forklift Throttle Golf Accelerator
Used for Curtis AC/DC Controller
This product can be costomized,Mini order:200pcs/1 item.
Throttle working voltage:48V
Throttle output :0----5V
Leads:with 500mm Leads
Mounting:2pcs 8mm Fixing holes in base
Rated Current : 300mA
Operating Temperature: -20°c to +60°c
RJSQ-001 Wiring Diagram:
Pin 1: Blue +48V output
Pin 2: Brown +48V working voltage input
Pin 3: Yellow/Green Throttle output 0-5V
Pin 4: Black Battery Negative(B-)
Ideal for tough environments such as material handling, foot pedals are used with Curtis electronic motor speed controllers, as well as models by other manufacturers. Designed for maximum installation flexibility and durability, these pedals are made of rugged aluminum castings.
The EFP-001 throttle is the simplest and most practical accelerator,Can be used with Curtis full range of products.
