Linde 0009763512 Albright DC182B-699 48V Forward/Reversing Changeover Contactor

Linde 0009763512 Albright DC182B-699 48V Forward/Reversing Changeover Contactor

Thermal Current Rating     100% 150A

Intermittent Current Rating 30%  275A

                                              70% 180A

The DC182 series of contactors has been designed for direct current loads, particularly motors as used on small electric vehicles such as light industrial trucks, powered invalid cars, etc.

They have double breaking main contacts with silver alloy contact tips, which are weld resistant, hard wearing and have excellent conductivity.

The DC182 main contact circuit, designed for motor reversing, is such that it has a built in failsafe, so that if both coils are energised simultaneously the contact arrangement is open circuits.

DC182 is a monoblock construction, resulting in a neat compact design which is compatible with modern electronic control systems. Main terminals can be configured in a variety of ways in order to suit the application.
